Operation > 47
3. This button prints a test page to ensure that your printer is working.
Advanced tab
1. You can specify which times of day your printer will be available.
2. Indicates current priority, from 1 (lowest) to 99 (highest). Highest priority
documents will print first.
3. Specifies that documents should be spooled (stored in a special print file) before
being printed. The document is then printed in the background, allowing your
application program to become available more quickly. Options follow:
This specifies that printing should not start until the last page has been spooled. If
your application program needs a lot of time for further computation in the middle of
printing, causing the print job to pause for more than a short period, the printer could
prematurely assume that the document has finished. Selecting this option would
prevent that situation, but printing will be completed a little later, as the start is
delayed.
This is the opposite choice to the one above. Printing starts as soon as possible after
the document begins spooling.
4. This specifies that the document should not be spooled, but printed directly. Your
application will not normally be ready for further use until the print job is complete.
This requires less disk space on your computer, since there is no spool file.
5. Directs the spooler to check the document setup and match it to the printer setup
before sending the document to print. If a mismatch is detected, the document is
held in the print queue and does not print until the printer setup is changed and the
document restarted from the print queue. Mismatched documents in the queue will
not prevent correctly matched documents from printing.
6. Specifies that the spooler should favour documents which have completed spooling
when deciding which document to print next, even if completed documents are lower
priority than documents which are still spooling. If no documents have completed
spooling, the spooler will favour larger spooling documents over shorter ones. Use
this option if you want to maximise printer efficiency. When this option is disabled
the spooler chooses documents based only on their priority settings.
NOTE
The above features are provided by the Windows XP operating system and will
vary with other operating systems.
1
2
3
4
5
6
7
8
9
10
My Printer Properties

Table of Contents

Other manuals for Oki B401dn

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Oki B401dn and is the answer not in the manual?

Oki B401dn Specifications

General IconGeneral
ColorNo
Duplex printingYes
Print technologyLED
Maximum resolution2400 x 600 DPI
Time to first page (black, normal)5.5 s
Print speed (black, normal quality, A4/US Letter)29 ppm
PCL fonts87
Bitmap fontsOCR-A, OCR-B
Printer fontsBitmap, PCL
Maximum duty cycle30000 pages per month
Recommended duty cycle2000 pages per month
Number of print cartridges-
Page description languagesEpson FX, IBM ProPrinter, PCL 5e, PCL 6
Processor familyPowerPC
Sound power level (standby)30 dB
Sound pressure level (printing)53 dB
Product colorWhite
Total input capacity250 sheets
Total output capacity150 sheets
Maximum input capacity251 sheets
Total number of input trays1
Multi-Purpose tray input capacity1 sheets
Maximum print size216 x 356 mm
Paper tray media typesPlain paper
Paper tray media weight60 - 120 g/m²
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 163 g/m²
Standard interfacesEthernet, Parallel, USB 2.0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (off)0.5 W
Power consumption (standby)70 W
Power consumption (printing)510 W
Power consumption (PowerSave)7 W
Storage temperature (T-T)-10 - 43 °C
Operating temperature (T-T)10 - 32 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)20 - 80 %
Compatible operating systemsWindows XP (32-bit & 64-bit) / Server 2003 (32-bit & 64-bit) / Vista (32-bit & 64-bit) / Server 2008 (32-bit & 64-bit) / Server 2008 R2 (64-bit) / 7 (32-bit & 64-bit); Mac OS X Intel 10.4-10.7
Mac operating systems supportedMac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supportedWindows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supportedWindows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Weight and Dimensions IconWeight and Dimensions
Dimensions (WxDxH)387 x 364 x 244.5 mm
