Oki C511 Maintenance Manual

44951501TH Rev.2
3-15
Oki Data CONFIDENTIAL
3. INSTALLATION
4. Touch the metal part of the printer to discharge static.
Metal part
5. Loosen the screw and remove the bracket.
Bracket
Screw
6. Insert an additional memory into the slot and push it against the
main unit.
Note! • Do not touch electronic parts or connector terminals.
• Install the memory by observing the correct orientation of it. The memory
has a notch in its edge so as to t with the memory slot connector.
7. Attach the bracket and tighten the screw.
Bracket
Screw
8. Connect the printer cable to the printer.
Printer cable
9. Attach the connector cover to the printer.
Connector cover

Oki C511 Specifications

General

Print Technology	LED
Print Speed (B&W)	30 ppm
Print Speed (Color)	26 ppm
Resolution	1200 x 600 dpi
Connectivity	USB 2.0, Ethernet
Operating Systems Supported	Windows, macOS, Linux
