Oki C511 Maintenance Manual

44951501TH Rev.2
4-17
Oki Data CONFIDENTIAL
4.REPLACEMENT OF PARTS
4.2.19 Side-L assembly, side-R assembly and base
assembly
.
(1) Remove the left side cover, the right side cover, the rear cover, the top cover
assembly, the operator panel assembly, the feeder assembly, the guide-ejection
assembly and the registration assembly.
(2 Remove the four (silver-colored) screws
to remove the plate-bottom .
(3) Remove the E-shaped retainer ring
and then the shaft .
(4) Remove the six (silver-colored) screws
to detach the side-L assembly , the
side-R assembly and the base assembly .

Oki C511 Specifications

General

Print Technology	LED
Print Speed (B&W)	30 ppm
Print Speed (Color)	26 ppm
Resolution	1200 x 600 dpi
Connectivity	USB 2.0, Ethernet
Operating Systems Supported	Windows, macOS, Linux
