Oki C531 Maintenance Manual

44951501TH Rev.2
5-14
Oki Data CONFIDENTIAL
5. MAINTENANCE MENUS
Table 5-4
Unit name displayed Driving restriction Remarks
ID MOTOR All of the (black, yellow, magenta and cyan)
image drums must be removed.
–
BELT MOTOR All of the (black, yellow, magenta and cyan)
image drums must be removed.
–
FUSER_MOTOR – –
REGIST MOTOR – –
T1 HOPPING MOTOR – –
FRONT MOTOR – –
REGIST SHUTTER – –
DUPLEX MOTOR – –
DUPLEX CLUTCH – –
T2 HOPPING MOTOR – Option
T2 FEED CLUTCH – Option
ID UP/DOWN The top and front cover must be closed. –
LV FAN TEST – –
ID FAN TEST – –
FRONT FAN TEST – –
Note: Display while ID UP/DOWN is in progress
MOTOR & CLUTCH TEST
ID UP/DOWN ***
***
: Identifies the number of executions
Display after holding down REGIST SHUTTER OK button
MOTOR & CLUTCH TEST
SHT ***
***
: Identifies the number of executions

Oki C531 Specifications

General

Print Technology	LED
Print Speed (Black)	30 ppm
Print Speed (Color)	30 ppm
Duplex Printing	Yes
Operating System Compatibility	Windows, Mac OS, Linux
Weight	22 kg
Connectivity	USB 2.0, Ethernet
Media Size	A4, A5, A6, B5, Letter, Legal, Envelopes
Resolution	Up to 1200 x 600 dpi
Input Capacity	250 sheets
