Oki C531 Maintenance Manual

44951501TH Rev.2
4-10
Oki Data CONFIDENTIAL
4.REPLACEMENT OF PARTS
4.2.10 Top cover assembly
(1) Remove the left side cover, the right side cover and the rear cover.
(2) Remove the plate shield assembly and then the LED head cables.
(3) Remove the two screws
to remove the plate-rear .
(4) Remove the (silver-colored) screw
and then the two E-shaped retainer rings
to detach the top cover .
4.2.11 Top cover and LED head cable assembly
(1) Demount the top cover assembly.
(2) Remove the 18 (black) screws
to detach the top cover .
(3) Remove the (silver-colored) screw
to detach the LED head cable assembly .
×18

Oki C531 Specifications

General

Print Technology	LED
Print Speed (Black)	30 ppm
Print Speed (Color)	30 ppm
Duplex Printing	Yes
Operating System Compatibility	Windows, Mac OS, Linux
Weight	22 kg
Connectivity	USB 2.0, Ethernet
Media Size	A4, A5, A6, B5, Letter, Legal, Envelopes
Resolution	Up to 1200 x 600 dpi
Input Capacity	250 sheets
