4.REPLACEMENT OF PARTS
4.2.14 MPT assembly
(1) Remove the cassette assembly.
(2) Open the MPT assembly
.
(3) Pull the MPT assembly in the direction of the arrow and release the two supports to
detach the MPT assembly.
