Oki C531 Maintenance Manual

44951501TH Rev.2
7-38
Oki Data CONFIDENTIAL
7. TROUBLESHOOTING
Lock lever
(blue)
Lock lever
(blue)
(8) Turn the lock levers inwards to lock the belt unit.
(9) Put the fuser unit back into position.
(10) Turn the lock levers inwards to lock the fuser unit.
(11) Install the image drum unit in the printer so as to situate the K toner cartridge
toward the front of the printer.
(12) Close the top cover.
Handle (blue)
Handle (blue)
Fuser unit lock levers (blue)
Handle
Fuser unit lock lever
(blue)
Fuser unit lock lever
(blue)

Oki C531 Specifications

General

Print Technology	LED
Print Speed (Black)	30 ppm
Print Speed (Color)	30 ppm
Duplex Printing	Yes
Operating System Compatibility	Windows, Mac OS, Linux
Weight	22 kg
Connectivity	USB 2.0, Ethernet
Media Size	A4, A5, A6, B5, Letter, Legal, Envelopes
Resolution	Up to 1200 x 600 dpi
Input Capacity	250 sheets
