Oki C532dn User Manual

- 121 -
7. Operating Management/ Specifications
1
Press the button to select [Setting] and press the (ENTER) button.
2
Press the button several times to select [Admin Setup] and press the
(ENTER) button.
3
Enter the administrator password, and then press (ENTER).
The factory default password is "999999".
4
Press the button several times to select [Manage Unit] and press the
(ENTER) button.
5
Press the button several times to select [Power Save] and press the
(ENTER) button.
6
Press the button several times to select [Sleep Time] and press the
(ENTER) button.
7
Press the or button to select time you want to set and press the
(ENTER) button.
8
Make sure that [*] is displayed on the left of the set time.
9
Press the (BACK) button to display the [Ready To Print] screen.
The machine does not enter Sleep mode in the following case.
• When an error occurs on the machine
• Access Control in the Access Control settings is enabled and Local IC Card or LDAP IC
Card in the Authentication Method is enabled.
The machine does not enter Deep Sleep mode in the following cases.
• IPSec is enabled
• A TCP connection is established
Example: A connection is established with Telnet or FTP.
When the transition time to enter Sleep mode or Deep Sleep mode from Power Save
mode elapses and the connection is disconnected, the machine enters Sleep mode.
• E-mail reception is enabled
• Wireless LAN is enabled
• Google Cloud Print is enabled
• LLTD is enabled
• IPv6 Global Address is assigned
In Deep Sleep mode, you cannot use the following protocols to print.
•NBT
In Deep Sleep mode, you cannot search or set by using the following functions and
protocols.
•NBT
In Deep Sleep mode, the following protocols that have the client function do not operate.
• E-mail alert*
2
•SNMP Trap
•WINS*
1
•SNTP*
2
Setting the Length of Idle Time Before Entering Sleep Mode Restrictions in Power Saving Function
*1 The elapse time in Deep Sleep mode is not included in the intervals of WINS update
time.
WINS regular updates are not performed in Deep Sleep mode, possibly resulting in
names that are registered in the WINS server being deleted.

Oki C532dn Specifications

General

Color	Yes
Print technology	LED
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	60000 pages per month
Recommended duty cycle	0 - 6000 pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PDF 1.7, PostScript 3, SIDM
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	1410 sheets
Paper tray 2 input capacity	530 sheets
Total number of input trays	1
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	9, 10, C5, DL, Monarch
Custom media width	64 - 216 mm
Custom media length	90 - 1321 mm
Paper tray media types	-
Paper tray media weight	64 - 176 g/m²
Non-ISO print media sizes	16K, Executive (184 x 267mm), Folio (media size), Index card, Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Photo paper sizes (imperial)	4x6, 5x7 \
Multi-purpose tray media types	Envelopes
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	64 - 220 g/m²
Display	LCD
Product color	Black, White
Display diagonal	7 \
Wi-Fi	No
Security algorithms	HTTPS, IPSEC, SNMP, SSL/TLS
Mobile printing technologies	Apple AirPrint, Google Cloud Print
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	2
Noise level (idle)	37 dB
Sound pressure level (printing)	54 dB
Sound pressure level (quiet mode)	52 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1250 W
Power consumption (printing)	670 W
Power consumption (PowerSave)	14 W
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2012 x64
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Storage temperature (T-T)	0 - 43 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC
Supported protocols	CP/IPv4&v6, NetBIOS over TCP, DHCP, DHCPv6, BOOTP, HTTP, HTTPS, DNS, DDNS, WINS, UPNP, Bonjour, SMTP, POP3, SNMPv1&v3, SNTP, IPP, IPPS, WSD Print, LLTD, IEEE802.1X, LPR, Port9100, Telnet, FTP, Google Cloud Print, Wireless IEEE802.11a/b/g/n, WEP, WPA, WPA2, Personal, Enterprise

Weight and Dimensions

Depth	571 mm
Width	427 mm
Height	279 mm
