Oki C532dn User Manual

- 64 -
3. Basic Operations
6
Insert the paper with the print side up until its edge touches the paper feed
entrance.
Do not load paper above the " " mark.
When a printer is in the power saving mode, press the (Power Save) button to restore from the mode.
7
Press the or button on the operator panel to select [Setting] and press
the (ENTER) button.
8
Select [Paper Setup], and then press the (ENTER) button.
9
Select the MP tray, and then press the (ENTER) button.
10
Set [Paper Size].
11
Set [Media Type].
12
Set [Media Weight].
13
Press the (ONLINE) button to return to the standby screen.
• Do not load paper in different sizes, types, or weights.
• When adding sheets of paper, remove paper loaded in the MP tray, bundle the whole batch of sheets, and align
edges of sheets to load them.
• Do not insert objects other than paper in the MP tray.
Store paper under the following conditions to maintain quality.
• Inside a cabinet or other dry and dark place
• On a flat surface
• Temperature: 20°C
• Humidity: 50% RH (relative humidity)
Do not store paper in the places as shown below:
• Directly on the floor
• Where paper is exposed to direct sunlight
• Near the inside of an exterior wall
• On an uneven surface
• Where static electricity may be generated
• Where temperature excessively rises high and temperature rapidly changes
• Near this machine, an air conditioner, a heater, or duct
• Do not unwrap paper until just before you use.
• Do not leave paper unwrapped for a long period. Doing so may result in printing problems.
• Depending on the print media, environment, storage conditions the print quality may deteriorate or printout may get
curled.
Paper storage

Oki C532dn Specifications

General

Color	Yes
Print technology	LED
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	60000 pages per month
Recommended duty cycle	0 - 6000 pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PDF 1.7, PostScript 3, SIDM
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	1410 sheets
Paper tray 2 input capacity	530 sheets
Total number of input trays	1
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	9, 10, C5, DL, Monarch
Custom media width	64 - 216 mm
Custom media length	90 - 1321 mm
Paper tray media types	-
Paper tray media weight	64 - 176 g/m²
Non-ISO print media sizes	16K, Executive (184 x 267mm), Folio (media size), Index card, Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Photo paper sizes (imperial)	4x6, 5x7 \
Multi-purpose tray media types	Envelopes
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	64 - 220 g/m²
Display	LCD
Product color	Black, White
Display diagonal	7 \
Wi-Fi	No
Security algorithms	HTTPS, IPSEC, SNMP, SSL/TLS
Mobile printing technologies	Apple AirPrint, Google Cloud Print
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	2
Noise level (idle)	37 dB
Sound pressure level (printing)	54 dB
Sound pressure level (quiet mode)	52 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1250 W
Power consumption (printing)	670 W
Power consumption (PowerSave)	14 W
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2012 x64
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Storage temperature (T-T)	0 - 43 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC
Supported protocols	CP/IPv4&v6, NetBIOS over TCP, DHCP, DHCPv6, BOOTP, HTTP, HTTPS, DNS, DDNS, WINS, UPNP, Bonjour, SMTP, POP3, SNMPv1&v3, SNTP, IPP, IPPS, WSD Print, LLTD, IEEE802.1X, LPR, Port9100, Telnet, FTP, Google Cloud Print, Wireless IEEE802.11a/b/g/n, WEP, WPA, WPA2, Personal, Enterprise

Weight and Dimensions

Depth	571 mm
Width	427 mm
Height	279 mm
