Maintenance > 62
3. Pull the two fuser retaining levers (b) towards the front of the printer so that they
are fully upright.
4. Holding the fuser by its handle (a), lift the fuser straight up and out of the printer. If
the fuser is still warm, place it on a flat surface which will not be damaged by heat.
5. Remove the new fuser from its packaging and remove the transit material.
6. Holding the new fuser by its handle, make sure that it is the correct way round. The
retaining levers (b) should be fully upright, and the two locating lugs (c) should be
towards you.
7. Lower the fuser into the printer, locating the two lugs (c) into their slots in the metal
partition which separates the fuser area from the image drums.
8. Push the two retaining levers (b) towards the rear of the printer to lock the fuser in
place.
9. Finally, close the output tray and press down firmly at both sides so that the cover
latches closed.
b
b
c
