Indication of consumable part counters
This self-diagnosis is practiced to indicate the consumed states of consumable parts.
1. Activate the normal self-diagnostic mode, and press and hold down the [MENU+] key or [MENU-] key, until
"CONSUMABLE STATUS" appears in the display section, and then, press the ENTER key. (The MENU+ key
increments a test item, and the MENU- key decrements a test item.)
2. Pressing the [MENU+] key or [MENU-] key causes the consumed states of consumable parts to be displayed
sequentially. (ONLINE and CANCEL keys inactive to pressing)
3. Press the [BACK] key to terminate the test. (Status of Item 1 restored)
Display Upper Display Lower Format Unit Function
K-ID UNIT ********IMAGES DEC Images
Y-ID UNIT ********IMAGES DEC Images
M-ID UNIT ********IMAGES DEC Images
C-ID UNIT ********IMAGES DEC Images
The number of rotation after a new
TONER ID of each color was attached.
The number is converted into A4 3Page/
Job.
FUSER UNIT ********PRINTS DEC Prints The number of sheets after a new FUSER unit was
attached.
TR BELT UNIT ********IMAGES DEC Images The number of sheets after a new BELT unit was attached
K-TONER (FULL) ********% DEC %
Y-TONER (FULL) ********% DEC %
M-TONER (FULL) ********% DEC %
C-TONER (FULL) ********% DEC %
The number of use of each color TONER.
M-WASTE TNR CNT ********TIMES DEC Times
C-WASTE TNR CNT
********TIMES DEC Times
The number of disposal TONER count.
*Disposal TONER becomes full in more than 32times.
K-STC MODE CNT ********TIMES DEC Times
Y-STC MODE CNT ********TIMES DEC Times
M-STC MODE CNT ********TIMES DEC Times
C-STC MODE CNT ********TIMES DEC Times
The printing dot counts of each color TONER cartridge.
(The count is NOT reset by replacing cartridge.)
K REFILL CNT ********TIMES DEC Times
Y REFILL CNT ********TIMES DEC Times
M REFILL CNT ********TIMES DEC Times
C REFILL CNT ********TIMES DEC Times
The printing dot counts of each color TONER cartridge.
(The count is reset by replacing cartridge.)
K OVER RIDE CNT ********TIMES DEC Times
Y OVER RIDE CNT ********TIMES DEC Times
M OVER RIDE CNT ********TIMES DEC Times
C OVER RIDE CNT ********TIMES DEC Times
The number of times that each color TONER cartridge life
was extended.
