B – 3
Figure 11-1 Upper Cover Assy
No. Part No. Description Q'ty
Q'ty
Remarks
Required
1 1PP4128-1186P6 Upper cover (N) 1 2 For ML3320 For INT
1PP4128-1186P4 Upper cover (N) 1 2 For ML3320 For OEL
1PP4128-1186P2 Upper cover (N) 1 2 For ML3320 For ODA
1PP4128-1231P6 Upper cover (W) 1 2 For ML3321 For INT
1PP4128-1231P4 Upper cover (W) 1 2 For ML3321 For OEL
1PP4128-1231P2 Upper cover (W) 1 2 For ML3321 For ODA
2 1PA4094-7305G10 Sheet guide assy (N) 1 2 For ML3320
1PA4094-7308G11 Sheet guide assy (W) 1 2 For ML3321
3 2PA4128-1237G1 Access cover assy (N) 1 2 For ML3320
2PA4128-1241G1 Access cover assy (W) 1 2 For ML3321
To Next Page
