Oki Microline 3320

3 – 6
3.3.2 Ribbon Protector
(1) Remove the printhead (see 3.3.1).
(2) Open the pull-up roller cover 1.
(3) Raise and remove the ribbon protector 2.
(4) To install, follow the removal steps in the reverse order.
1
2
