Oki Microline 3320 - Page 135

B – 7
Figure 11-3 Printer Unit
No. Part No. Description Q'ty
Q'ty
Remarks
Required
1 3PA4044-5002G2 Main chassis assy (N) 1 2 For ML3320
3PA4044-5152G2 Main chassis assy (W) 1 2 For ML3321
2 3PP4044-5012P1 Bottom paper end lever 1 1
3 4PP4044-5019P2 Pressure spring (F) 3 2 For ML3320
4PP4044-5019P1 Pressure spring (F) 5 4 For ML3321
4 4PP4044-5031P2 Roller holder (F) 3 6 For ML3320
5 8 For ML3321
5 4PA4025-3327G1 Front pressure roller 3 6 For ML3320
5 8 For ML3321
6 3PP4044-5015P1 Release shaft (N) 1 2 For ML3320
3PP4044-5157P1 Release shaft (W) 1 2 For ML3321
7 1PP4044-5021P1 Paper pan plate (N) 1 2 For ML3320
1PP4044-5158P1 Paper pan plate (W) 1 2 For ML3321
8 3PP4025-3320P2 Leaf spring (N) 1 2 For ML3320
3PP4025-3507P2 Leaf spring (W) 1 2 For ML3321
9 3PP4044-5011P1 Paper end lever 1 1
10 3PP4044-5013P1 Sensor lever 1 1
11 4PP4025-3340P1 Change gear 1 2
12 3PP4025-3341P1 Tractor gear 1 2
13 4PP4044-5020P1 Pressure spring (R) 3 2 For ML3320
3 2 For ML3321
14 4PP4044-5163P1 Pressure spring (W) 2 1 For ML3321
15 3PP4044-5033P1 Roller holder (R) 3 6 For ML3320
5 10 For ML3321
16 4PP4044-5017P1 Change arm lever 1 2
17 3PP4044-5014P1 Switch lever 1 1
18 4PP4044-5024P1 Idle gear (PLT) 1 2
19 2PP4044-5016P1 Change lever 1 2
20 3PP4044-5023P1 Reset spring D 1 2
21 3PA4044-5110G1 LF motor assy 1 4
22 3PP4044-5034P1 Rear pressure roller (N) 1 2 For ML3320
3PP4044-5162P1 Rear pressure roller (W) 1 2 For ML3321
