1.6.13 Paper Feed Methods
Standard
Friction Feed (Top)
Rear Push Tractor (Rear)
Optional
Pull Tractor (Bottom)
Bottom Push Tractor Feed (Bottom)
Single-Bin Cut Sheet Feeder (Top)
CSF 5000 - Narrow
CSF 5001 - Wide
1.6.14 Paper Feed Paths
Top Feed (Standard)
Rear Feed (Standard)
Bottom Feed (by using an Optional feed mechanism)
Special Features
Paper Park
Automatic Paper Loading
Forms Tear Off
1.6.15 Paper Loading
Auto Loading (Top Feed)
Press FORM FEED / Load switch to feed paper to default position
1.6.16 Paper Out Detection
Distance from end of paper
Rear Feed: 0.5 inches (12.7 mm)
Bottom Feed: 0.5 inches (12.7 mm)
Top Feed: 0.5 inches (12.7 mm)
1.6.17 Paper Tear Capabilities
Forms Tear-0ff (sharp edge on access cover)
Metal Tear Bar (with optional bottom feed tractor unit)
Specifications 1 - 10 Microline 520/521 Service Handbook
P/N 59257803
