18 ML3390/91

Group Item Settings

Set-Up Operator Panel Function Full Operation, Limited Operation

(continued) Reset Inhibit No, Yes

Print Suppress Effective Yes, No

Auto LF No, Yes

Auto CR* No, Yes

SI Select Pitch (10 cpi)* 17.1 cpi, 15 cpi

SI Select Pitch (12 cpi)* 20 cpi, 12 cpi

Time Out Print Valid, Invalid

Auto Select No, Yes

Graphics Speed Low, High

Centring Position DEFAULT, MODE1, MODE2**

Parallel I/F I-Prime Buffer Print, Invalid, Buffer Clear

Pin 18 +5V, Open

Auto Feed XT*** Invalid, Valid

Appears only when the IBM emulation is selected.

** ML3391 only.

*** Applies only when the Epson emulation is selected.

3390hlp3.pm6 22/03/96, 16:0518

Questions and Answers:

Need help?

Do you have a question about the Oki ML3390 and is the answer not in the manual?

Oki ML3390 Specifications

General

Color	No
Built-in barcodes	Code 39, UPC-A, UPC-E
Maximum resolution	360 x 360 DPI
Maximum printing width (columns)	160
Media thickness	165 x 91 mm
Print technology	Dot matrix
Dimensions (WxDxH)	398 x 345 x 116 mm
Power requirements	220/230 VAC, 240V AC
Connectivity technology	Wired
Recommended media weight	45 - 90 g/m²
Sound pressure level (printing)	57 dB
Mean time between failures (MTBF)	10000 h
