Oki ML3390 User Manual

Help Guide 23
English
Specifications
Print Method Impact dot matrix
Printhead 24 pins, 0.20 mm diameter, thermal protection
Print Speed
Characters per Line (CPL)
Setting ML 3390 ML 3391
10 cpi 80 cpl 136 cpl
12 cpi 96 cpl 163 cpl
15 cpi 120 cpl 204 cpl
17.1 cpi 137 cpl 233 cpl
20 cpi 160 cpl 272 cpl
Emulations Epson LQ, IBM Proprinter, IBM AGM
co-resident
Interface Standard: Centronics parallel
Optional: RS-232C serial
Graphics
Resolution 360 x 360 dpi maximum
Receive Buffer Size 23K
DLL RAM 15K maximum (Epson emulation only)
Pitch, Characters Speed, Characters
Mode per Inch per Second
High Speed Draft 15 cpi 390 cps
Utility 10 cpi 260 cps
12 cpi 312 cps
17.1 cpi 223 cps
20 cpi 260 cps
Letter Quality 10 cpi 87 cps
12 cpi 104 cps
15 cpi 130 cps
17.1 cpi 149 cps
20 cpi 174 cps
3390hlp3.pm6 22/03/96, 16:0523

Oki ML3390 Specifications

General

Color	No
Built-in barcodes	Code 39, UPC-A, UPC-E
Maximum resolution	360 x 360 DPI
Maximum printing width (columns)	160
Media thickness	165 x 91 mm
Print technology	Dot matrix
Dimensions (WxDxH)	398 x 345 x 116 mm
Power requirements	220/230 VAC, 240V AC
Connectivity technology	Wired
Recommended media weight	45 - 90 g/m²
Sound pressure level (printing)	57 dB
Mean time between failures (MTBF)	10000 h
