Help Guide 19
English
Explanations of Menu Items
Auto CR (IBM). If you want the printer to automatically add
a carriage return when a Line Feed is received at the end of a
line, change the setting to Yes.
Auto LF. If your printout is consistently double spaced, select
No; if it overprints, select Yes.
Auto Feed XT (Epson). If your system uses pin 14 of the
parallel interface to control automatic line feed, change the
setting to Valid.
Auto Select. If you always use the same Top of Form position,
change the setting to Yes.
Bottom Margin. Change to Invalid if you want the printer to
ignore the bottom margin setting. Caution! This can cause
loss of data and damage the printhead.
Centring Position. Choose DEFAULT, Mode 1 or Mode 2.
Character Set. Choose IBM Set I or IBM Set II.
Code Page. Choose the Code Page character set you wish to
use.
Emulation Mode. Choose the printer emulation.
Form Tear-Off. Choose 500 mS, 1 sec, or 2 sec to turn the
Form Tear-Off feature on and to set the time interval for the
printer to wait before advancing the paper.
Graphics. Change to bidirectional graphics for faster printing:
optimise the registration using the Print Registration menu
item.
I-Prime. Determines what the printer will do when it receives
the I-Prime signal from the host: Buffer Print prints out the
buffer contents before resetting; Buffer Clear dumps the buffer
contents immediately. Invalid causes the printer to ignore the
I-Prime signal.
Language Set. Replaces certain standard symbols with special
characters used in foreign languages.
Line Spacing. Change to 8 lpi to get more lines on a page.
Operator Panel Function. Change to Limited Operation to
deactivate the PRINT QUALITY and CHARACTER PITCH
buttons. This prevents these from being changed via the control
panel when several people are using the printer.
