Oki ML3390 User Manual

22 ML3390/91
This feature is normally turned off. To activate it: Note: Some programs pause occasionally while sending
data. If the pause is too long, the paper will advance
to the tear-off position until more data is received.
This extra paper movement can cause uneven print
registration in graphics. If you have this problem,
use the menu to turn off this feature.
Paper Park Feature
1. Press SHIFT (➋) + SEL (➊).
2. Press GROUP (➌) until one of the following lines
appears, depending on which paper feed you are using:
REAR FEED Form Tear-Off OFF
BOTTOM FEED Form Tear-OFF OFF
3. Press SET (➍) consecutively until the time interval you
wish to select appears in the third column.
4. Press SHIFT (➋) + SEL (➊) to exit Menu Mode and
save the setting.
To retract rear-feed paper form the paper path, press PARK (➊).
QUIETPARKTEAR FF/LOAD
LF
SEL
SEL
POWER ALARM
MENU
GROUPEXIT
ITEM SET
PRINT
MENU
SHIFT TOF
Micro Feed
Up
Micro Feed
Down
➋
➌➊
➍
QUIETPARKTEAR FF/LOAD
LF
SEL
SEL
POWER ALARM
MENU
GROUPEXIT
ITEM SET
PRINT
MENU
SHIFT TOF
Micro Feed
Up
Micro Feed
Down
➊
3390hlp3.pm6 22/03/96, 16:0522

Oki ML3390 Specifications

General

Color	No
Built-in barcodes	Code 39, UPC-A, UPC-E
Maximum resolution	360 x 360 DPI
Maximum printing width (columns)	160
Media thickness	165 x 91 mm
Print technology	Dot matrix
Dimensions (WxDxH)	398 x 345 x 116 mm
Power requirements	220/230 VAC, 240V AC
Connectivity technology	Wired
Recommended media weight	45 - 90 g/m²
Sound pressure level (printing)	57 dB
Mean time between failures (MTBF)	10000 h
