Oki ML3410 User Manual

Load Vertical
For-mat Unit
(VFU)channel
data
ESC XDATAESC
Y
27 88 DATA27
89
1B 58 DATA1B
59
VFU can set up
to 14channels on
a formmax. of
132
lines.Channel
data isbitmapped
to 2 bytesfor
each line. First
byteallocated to
channels 1(lsb)
to 7; second
byteallocated to
channels 8(lsb)
to 14. Msb
isignored. ESC Y
indi-cates end of
data.
Set page length
inlines
ESC 2 n 27 50 n 1B 32 n Also sets Top of
Form atcurrent
position.n = 1 to
128 (# of lines)
Cut Sheet
FeederControl
(option)
Insert page ESC I 27 73 1B 49
Eject page ESC J 27 74 1B 4A
Select bin ESC EM n 27 25 1B 19 n n = 1: bin 1n = 2:
bin 2
Character Sets
Select custom
(DLL) character
set
ESC K 27 75 1B 4B
Select
standardcharacte
r set
ESC L orESC M 27 76 or 27 77 1B 4C or 1B 4D
Create
Utilityascender
customcharacter
set
ESC %
Aaddressdata
27 37
65addressdata
1B 25
41addressdata
Character rests
onbaseline.addre
ss = location
ofcharacter (dec.
32 to127)data =
1 byte for eachof
11 columns of 7
dots;lsb is top
dot
ML3410 ( 96-02-07 )

Oki ML3410 Specifications

Print Specifications

printhead	9 pin
print speed at 10 cpi	HSD 550 cps, Utility 417 cps, NLQ 104 cps
graphics resolution	1445216 dpi maximum

Paper Handling

paper weight	12 to 24 lb
paper thickness top feed	0.36 mm (0.014 inches) maximum
paper thickness bottom feed	0.50 mm (0.020 inches) maximum

Operating Environment

operating temperature	50 to 104 degrees F (10 to 40 degrees C)
storage temperature	14 to 122 degrees F (-10 to +50 degrees C)
humidity	20 to 80% RH

Electrical Requirements

voltage	120 volts, +5.5%/-15% 220/240 volts, ±10%
frequency	50/60 Hz, ±2 Hz
power idling	30 watts
power operating	75 watts

Weight and Dimensions

width	25-1/4 inches (540 mm)
depth	19 inches (483 mm)
height	15 inches (203 mm)
weight	63 lbs. (25.4 kg)
