Oki ML3410 User Manual

Create
Utilitydescender
customcharacter
set
ESC %
Daddressdata
27 37
68addressdata
1B 25
44addressdata
Character
extends 2dots
below
baseline.address
= location
ofcharacter (dec.
32 to127)data =
1 byte for eachof
11 columns of 7
dots;lsb is top
dot
Create NLQ
customcharacter
ESC %
Waddresswidthd
ata
27 37
87addresswidthd
ata
1B 25
57addresswidthd
ata
address =
location
ofcharacter (32
to 127dec.)width
= width
ofcharacter in dot
col-umnsCharact
ers are max.
17dots high;
each
columnrequires 3
bytes ofdata.
Print Features
Select
NLQsinglepass
ESC 7 27 55 1B 37
Select
NLQdualpass
ESC 9 27 57 1B 39
Select Utility ESC 8 27 56 1B 38
Set 10 cpi pitch ESC 6 27 54 1B 36
Set 12 cpi pitch ESC A 27 65 1B 41
Set 17.1 cpi pitch ESC B 27 66 1B 42
17.1 cpi
pitchoneline only
DC2 18 12 Setting clears
when lineis
terminated.
Start
double-widthprint
ing
ESC C 27 67 1B 43
Stop
double-widthprint
ing
ESC Z 27 90 1B 5A
Double-widthprint
ingone lineonly
SO 14 0E Setting clears
when lineis
terminated.
Start
superscriptprintin
g
ESC F 27 70 1B 46
ML3410 ( 96-02-07 )

Oki ML3410 Specifications

Print Specifications

printhead	9 pin
print speed at 10 cpi	HSD 550 cps, Utility 417 cps, NLQ 104 cps
graphics resolution	1445216 dpi maximum

Paper Handling

paper weight	12 to 24 lb
paper thickness top feed	0.36 mm (0.014 inches) maximum
paper thickness bottom feed	0.50 mm (0.020 inches) maximum

Operating Environment

operating temperature	50 to 104 degrees F (10 to 40 degrees C)
storage temperature	14 to 122 degrees F (-10 to +50 degrees C)
humidity	20 to 80% RH

Electrical Requirements

voltage	120 volts, +5.5%/-15% 220/240 volts, ±10%
frequency	50/60 Hz, ±2 Hz
power idling	30 watts
power operating	75 watts

Weight and Dimensions

width	25-1/4 inches (540 mm)
depth	19 inches (483 mm)
height	15 inches (203 mm)
weight	63 lbs. (25.4 kg)
