Adding a Printer With the LPD Protocol (TCP/IP)
2
Printing Basic Operation
3 Select [IP] to display the screen below.
Enter data in [Address:], [Queue:],
and [Name:] then check that your
printer
is selected in [Use:] and click
[Add].
(1)
(2)
(3)
(4)
(1) Enter the IP address assigned to the
printer.
(2) Enter [lp] in [Queue:].
(3) At rst, the IP address entered in
(1) is displayed. You can enter any
name.
B731(LPD) is displayed as an example here.
(4) Your printer (PS) is displayed
automatically in [Use:].
If communication is not performed
correctly with the printer, it is not
automatically selected.
Note
● If you use Mac OS X 10.7 or later, the driver is not
automatically selected when the printer is in the
sleep mode.
Please restore the printer from the sleep mode, and
enter data in [Address].
4 Perform optional settings for the printer,
and click [OK].
5 Return to the [Print & Scan] dialog
box. Your printer (LPD) is added to
the printer list. Select your printer
(LPD)
in [Default printer].
Your printer is used for printing as default.
Procedures for adding a printer are completed.
Close the [Print & Scan] dialog box.

Oki MPS5501B Specifications

General

Print Speed	55 ppm
Resolution	1200 x 1200 dpi
Standard Paper Capacity	630 sheets
Connectivity	USB 2.0, Ethernet
Max Paper Size	A4
Maximum Paper Capacity	3160 sheets
