Oki MPS5501B User Manual

- 92 -
When an Error Message is Displayed on the Display Screen
4
Troubleshooting
3 Remove the print cartridge (4) and place
them on a at surface.
4
4 Cover the print cartridge (4) with paper
so that it will not be exposed to light.
4
5 Remove the jammed paper remaining
inside of the unit.
6 Hold the fuser unit handle (5) and lift
the fuser unit out of the printer.
CAUTIO
N
Possible to get burned.
● The fuser unit is extremely hot. Do not touch it.
5
7 Tilt the release levers (6) on the fuser
unit forward, and be sure to pull out the
jammed paper forward gently.
6

Oki MPS5501B Specifications

General

Print Speed	55 ppm
Resolution	1200 x 1200 dpi
Standard Paper Capacity	630 sheets
Connectivity	USB 2.0, Ethernet
Max Paper Size	A4
Maximum Paper Capacity	3160 sheets
