Oki MPS5501B User Manual

- 96 -
When an Error Message is Displayed on the Display Screen
4
Troubleshooting
3 Return the tray (1) to its original
position.
1
4 Insert your nger into the recess on
the right side of the printer and pull the
front cover open lever (2) to open the
front cover (3) forward.
Note
● Open the front cover gently. If you open it rapidly,
the MP Tray may open.
3
2
5 Close the front cover (3).
3
Removal of jammed paper is completed.
Memo
● Open then close the front cover after removing the
jammed paper. Otherwise, the error indication do not go
out.

Oki MPS5501B Specifications

General

Print Speed	55 ppm
Resolution	1200 x 1200 dpi
Standard Paper Capacity	630 sheets
Connectivity	USB 2.0, Ethernet
Max Paper Size	A4
Maximum Paper Capacity	3160 sheets
