2 TECHNICAL SPECIFICATIONS
The technical specifications are medial values. During operation slight variations are possible.
2.1 CONTROL UNIT
Dimensions (L x W x H) 360 x 320 x 140 mm
Weight 1.6 kg
Input (max) 19 V DC, 3.16 A, 60 W
Processor / Main CPU Cortex M3, 32 MHz
Processor / Slave CPU Cortex M0, 24 MHz
Display 3.5” Resistive touch, 480 x 320 Pixel
Display CPU Cortex M3, 32 MHz, 128 KB RAM
Data memory 4 GB
Sample rate 1024 values / second
Measurement resolution 16 bit
Operating temperature -10 – 60 °C
Storage temperature -20 – 70 °C
Audio Internal speaker / Bluetooth
Air humidity 5 % – 75 %
Waterproof No
2.2 WIRELESS DATA TRANSFER
Technology Bluetooth 5.1
Frequency range 2.402 – 2.480 GHz
Maximum transfer rate 1 Mbps
Maximum Transmitting Power: +8 dBm
Maximum Range: approx. 10 m
2.3 STANDARD PROBE
Length 445 mm
Diameter, Shaft / LED Orbit 35 mm / 65 mm
Weight 0.4 kg
Sensor technology SCMI-15-D
2.4 SUPER SENSOR
Length 960 mm
Diameter, Shaft / LED Orbit 50 mm / 65 mm
Weight 0.9 kg
Sensor technology SCMI-15-D
