4742-E P-33
SECTION 1 INVERTER UNIT (MIV UNIT)
Controller ID No. Tables
(1) ID Numbers of Lathes' and Grinders' OSP
NOTICE
Controller
ID No.
ID No. Switch Setting
Axis Category
Axis
Name
Description
12345
1 ON 1st NC controlled axis XA A saddle side X-axis, or R side X-axis
2 ON 2nd NC controlled axis YA Y-axis
3 ON ON 3rd NC controlled axis ZA A saddle side Z-axis, or R side Z-axis
4 ON 4th NC controlled axis WA W-axis or ZC-axis
5 ON ON 5th NC controlled axis SA 1st spindle or R side spindle
6 ON ON 6th NC controlled axis MA A saddle side M-axis, or R side M-
axis
7 ON ON ON 7th NC controlled axis XB B saddle side X-axis, or L Side X-axis
8 ON 8th NC controlled axis ZB B saddle side Z-axis, or L side Z-axis
9 ON ON 9th NC controlled axis SB Spindle 2 or L side spindle
10 ON ON 10th NC controlled axis MB B saddle side M-axis, or L side M-axis
11 ON ON ON 11th NC controlled axis LXA
(RZA)
Loader X-axis, or loader R side X-axis
Robot RZA-axis
12 ON ON 12th NC controlled axis LYA
(RCA)
Loader Y-axis, or loader R side Y-axis
Robot RCA-axis
13 ON ON ON 13th NC controlled axis LZA Loader Z-axis, or loader R side Z-axis
14 ON ON ON 14th NC controlled axis LXB Loader L side X-axis
15 ON ON ON ON 15th NC controlled axis LYB Loader L side Y-axis
16 ON 16th NC controlled axis LZB Loader L side Z-axis
17 ON ON 17th NC controlled axis Spare
18 ON ON 18th NC controlled axis Spare
19 ON ON ON 19th NC controlled axis Spare
20 ON ON 1st PLC controlled axis TA A saddle turret rotation axis
21 ON ON ON 2nd PLC controlled axis TB B saddle turret rotation axis
22 ON ON ON 3rd PLC controlled axis GA ATC magazine axis
23 ON ON ON ON 4th PLC controlled axis EC ATC EC axis
24 ON ON 5th PLC controlled axis EZ ATC EZ axis
25 ON ON ON 6th PLC controlled axis PA/
(OCA)
AAC PA axis / (Electric cylinder)
26 ON ON ON 7th PLC controlled axis GB/
(OTA)
ATC 2nd magazine / (Turret clamp)
27 ON ON ON ON 8th PLC controlled axis Spare
28 ON ON ON 9th PLC controlled axis Spare
29 ON ON ON ON SFT* Safety speed monitor (1 to 3)
Blank box in the ID No. Switch Setting column indicate "OFF".
