SECTION 2 DC POWER SUPPLY UNIT (MPS, MPR UNIT)
7. Connection
7-1. System Connection
Eeospcsa2018
Refer to 7-1 "System Connection" in Section 1.
7-2. Terminal Block Screw Size
Eeospcsa2019
Refer to 8 "DC Power Supply Unit External Dimensions".
7-3. Connectors
Eeospcsa2020
(1) Connector name: C
Type (manufacturer): 53460-0611 (Molex)
Pin layout
(2) Connector name: DCA/B
Type (manufacturer): 1-178137-2 (AMP)
Pin layout
(3) Connector name: OPR
Type (manufacturer): 178303-2 (AMP)
Pin layout
(4) Connector name: MC
Type (manufacturer): 1-179276-2 (AMP)
Pin layout
(5) Connector name: ACA
Type (manufacturer): 1-178138-2 (AMP)
Pin layout
M4 terminal block is used for MPS20, MPS30, MPS45 and MPS60.
1SG2SG
3 PSRDY-N 4 SVALM-N
5PSD6PSD-N
A-1 +24 V B-1 +24 V
A-2 SG B-2 SG
A-3 N.C. B-3 N.C.
B-1 DBRC A-1 DBRC-N
B-2 PWON A-2 PWON-N
B-3 OPRON A-3 OPRON-N
1MC
2MCCOM
1R
2S
2T
