SECTION 2 DC POWER SUPPLY UNIT (MPS, MPR UNIT)
2-2. Configuration of Power Supply Units
Eeospcsa2004
Component parts of a power supply unit are indicated below.
2-2-1. Power Regeneration Type MPS Unit
Eeospcsa2005
(1) MPS unit: power regeneration type
Configuration of I set of power supply unit: PSB + MFP1 card + MPS PU + MPS-ACL
In the table below, indication of "(1)" in the Q'ty column indicates that any of the indicated units
should be selected meeting the motor capacity.
2-2-2. Resistor Regeneration Type MPR Unit
Eeospcsa2006
(1) MPR unit: resistor regeneration type
Configuration of 1 set of power supply unit: MPR* PU
Category Order Name Q'ty Order No. Description
Control board
PSB-MPS10 (1) 1006-2103 Power regeneration type control board for
MPS10
PSB-MPS30 (1) 1006-2104 Power regeneration type control board for
MPS20 to 60
Display card MFP1 CARD 1 1006-2105 Card with status indicator
Power regeneration
type unit
MPS10 PU (1) 1006-2200 DC power supply unit: Continuous power
supply capacity 11 kW (15 hp)
MPS20 PU (1) 1006-2201 DC power supply unit Continuous power
supply capacity 20 kW (27 hp)
MPS30 PU (1) 1006-2202 DC power supply unit: Continuous power
supply capacity 30 kW (40 hp)
MPS45 PU (1) 1006-2203 DC power supply unit: Continuous power
supply capacity 45 kW (60 hp)
MPS60 PU (1) 1006-2204 DC power supply unit: Continuous power
supply capacity 60 kW (80 hp)
AC choke coil
MPS10-ACL (1) 1006-2285 AC reactor for MPS10 (with Capacitor)
MPS20-ACL (1) 1006-2281 AC reactor for MPS20 (with Capacitor)
MPS30-ACL (1) 1006-2282 AC reactor for MPS30 (with Capacitor)
MPS45-ACL (1) 1006-2283 AC reactor for MPS45 (with Capacitor)
MPS60-ACL (1) 1006-2284 AC reactor for MPS60 (with Capacitor)
Category Order Name Q'ty Order No. Description
Resistor regeneration
type unit
MPR5 PU (1) 1006-2205 DC power supply unit: Continuous power
supply capacity 5 kW (6.7 hp)
MPR10 PU (1) 1006-2206 DC power supply unit: Continuous power
supply capacity 10 kW (13.3 hp)
