4742-E P-4
SECTION 1 INVERTER UNIT (MIV UNIT)
(2) 2-axis specification MIV unit: for BL motors
Configuration of 1 set of MIV unit: Control board + Display card + Inverter unit
In the table below, indication of "(1)" in the Q'ty column indicates that any of the indicated units
should be selected meeting the motor capacity.
(*1) ICB1H-S is upward compatible with ICB1and ICB1F.
Category Order Name Q'ty Order No. Description
Control board
ICB1 (1) 1006-2100 BL motor 2-axis control board
(Discontinued)
ICB1F (1) 1006-2110 BL/PREX motor 2-axis control board
(Discontinued)
ICB1H (1) 1006-2120 BL/PREX motor board (*1)
Display card MFP1 CARD 1 1006-2105 Card with status indicator
Inverter unit
MIV0101-1 PU (1) 1006-2224 2-axis control inverter unit:
Applicable motor capacity 1.8 kW
× 1.8 kW
(2.4 hp
× 2.4 hp)
MIV0102-1 PU (1) 1006-2225 2-axis control inverter unit:
Applicable motor capacity 1.8 kW
× 2.8 kW
(2.4 hp
× 3.73 hp)
MIV0202-1 PU (1) 1006-2226 2-axis control inverter unit:
Applicable motor capacity 2.8 kW
× 2.8 kW
(3.73 hp
× 3.73 hp)
MIV0103-1 PU (1) 1006-2227 2-axis control inverter unit:
Applicable motor capacity 1.8 kW
× 3 kW
(2.4 hp
× 4 hp)
MIV0203-1 PU (1) 1006-2228 2-axis control inverter unit:
Applicable motor capacity 2.8 kW
× 3 kW
(3.73 hp
× 4 hp)
MIV0303-1 PU (1) 1006-2229 2-axis control inverter unit:
Applicable motor capacity 3 kW
× 3 kW
(4 hp
× 4 hp)
MIV0104-1 PU (1) 1006-2230 2-axis control inverter unit:
Applicable motor capacity 1.8 kW
× 4 kW
(2.4 hp
× 5.3 hp)
MIV0204-1 PU (1) 1006-2231 2-axis control inverter unit:
Applicable motor capacity 2.8 kW
× 4 kW
(3.73 hp
× 5.3 hp)
MIV0404-1 PU (1) 1006-2232 2-axis control inverter unit:
Applicable motor capacity 4 kW
× 4 kW
(5.3 hp
× 5.3 hp)
