TITLE
Service Manual
LCD TV For 237-T11
Doc No. SM_237-T11_19Nov07
Version 1.2
Page 19/72
Company Confidential-DRAFT
5. Disassembly
5-1 Stand
5-2 Back Cover
1. Loosen and remove 8 screws.
2. Safely remove the Stand.
1. Loosen and remove 17 screws.
2. Safely remove the Back Cover.
Screw T4*45-PH-Cross-Black
Screw T4*25-PH-Cross-Black
Screw MT4x8-PH-Cross-Black
SCREW T4 X 12
To Next Page
