TITLE
Service Manual
LCD TV For 237-T11
Doc No. SM_237-T11_19Nov07
Version 1.2
Page 43/72
Company Confidential-DRAFT
10. Parts List and Photo
10-1 PARTS LIST For LPL WX1-SL01 (See 10.2 Parts Photo)
237-T11 For WX1-SL01 Parts List-SL01(FM1-037000EGS25)
Item
Parts Name Parts NO.
1
537 MDA3 power module
EEC-PWAEP01G000
2
LG 37" LCD panel (w/AI)
ELP-37WX1SLG000
3
P0519 MDA3 System PCBA
SC0-P519201GMI4
4
MDA3 Keypad PCBA
SC0-P517701GMI0
5
37C_B_FRONT _MODULE_L9524_TCV
SX0-0000324G000
6
37C_B_Back Cover MODULE_TCV
SX0-0000320G000
7
Flat Cable Clip_FAA51-PG
EEC-FCFAA51G000
8
32_37C_KEYPAD_BUTTON
MP0-0000497G000
9
Graphic Label for MDA3
ML0-0000263G000
10
37C_Support Metal Assy_MDA3
SX0-0000273G000
11
37C WALLMOUNT Module
SX0-0000274G000
12
MTK 32" LPL LVDS wire
ECB-5LC0118G000
13
SCREW T4 X 12
MS0-WA34012G000
14
SCREW /NI/MT4*8
MS0-FA14008G000
15
SCREW MT4*8-PH-CROSS-BLACK
MS0-WA34008G000
16
SCREW T3*8 Black
MS0-WA33008G000
17
SCREW MT3*6-PH-CROSS-Black
MS0-A133006G000
18
SCREW /T4*10/Ni
MS0-WA14010G000
19
TV barcode label
ML0-0000016G000
20
S/N lebel 15*44mm
ML0-0000015G000
21
RIBBON
MX0-0000000G000
22
Heatproof tape
MP2-0000175G000
23
237T Marketing Label_GP
ML0-1000155G000
24
537_542 tech label-Dolby
ML0-0000314G002
25
MD1 40" keypad wire+Magnet buckle
SX0-0000446G000
26
37C_Speaker_Module_R+ Magnet buckle
SX0-0000441G000
27
37C_Speaker_Module_Left+ Magnet buckle
SX0-0000442G000
28
Power on Label-2
ML0-0000438G000
29
37" Panel Protection Film
MP0-0000730G000
30
Screw T4*45-PH-Cross-Black
MS0-1A34045G000
31
Screw T4*25-PH-Cross-Black
MS0-BA34025G000
32
37C_STAND_COVER_2nd
MP0-0000535G001
33
32 FOOT PAD
MM0-0000034G000
34
Condnctive shielding tapeVGA Port
EEC-EM13234G000
35
Condnctive shielding tape
EEC-EM30202G000
36
Condnctive shielding tape
EEC-EML10W2G000
37
Condnctive shielding tape
EEC-EM22033G000
38
Magnet buckle-B15-UH-13x23x7
EEC-PLB15UHG000
39
337 claspless cushion bottom
MP2-1000043G000
To Next Page
