TITLE
Service Manual
LCD TV For 237-T11
Doc No. SM_237-T11_19Nov07
Version 1.2
Page 25/72
Company Confidential-DRAFT
5-6 Panel Module
1. Loosen and remove 18 screws.
2. Take off the 37C_Support Metal Assy_MDA3
Screw MT4x8-PH-Cross-Black
Screw M4x12-Black
MT3*6-PH-CROSS-Black
