Olevia 237T Service Manual

TITLE
Service Manual
LCD TV For 237-T11
Doc No. SM_237-T11_19Nov07
Version 1.2
Page 7/72
Company Confidential-DRAFT
2. Specifications
PRODUCT SPECIFICATIONS
LCD Panel 37" TFT 37" TFT(LPL-WX4)
Power Management
(Standby Mode)
＜
＜＜
＜ 1W ＜
＜＜
＜ 1W
Displayable Resolution VGA 1360*768 max. VGA 1366*768 max.
Pixel Pitch 0.200mm * 0.600mm * RGB 0.200mm*0.600mm*RGB
LCD Display Color 8-bit, 16.7M colors 8-bit, 16.7 M colors
Viewing Angle CR>10
R/L 178 (Typ.)
U/D 178(Typ.)
CR>10
R/L 178 (Typ.)
U/D 178(Typ.)
Contrast Ratio 800:1 (Typ.) 1000:1 (Typ.)
Response Time 9ms (Gray to Gray) 9ms (Typ.)
Active Display Area H: 819.6mm, V:460.8mm H: 819.6mm, V:460.8mm
RF Tuner ATSC/NTSC Hybrid Terrestrial
Video Module
Input level: ~107dBµV
Range: NTSC 55 to 804 MHz,
2-69 channels for Off-Air and
2-125 channels for CATV
ATSC/NTSC Hybrid
Terrestrial Video Module
Input level: ~107dBµV
Range: NTSC 55 to 804 MHz,
2-69 channels for Off-Air and
2-125 channels for CATV
Power Voltage: 100~240 V
Consumption: 190W
Voltage: 100~240 V/
AC/50~60Hz
Consumption: 190W
2.5A(MAX)
Speaker 15W 15W
Compliance FCC, cUL, CSA, Energy Star FCC, cUL, CSA, Energy Star
Temperature
Operating: 0℃
℃℃
℃~40℃
℃℃
℃
Storage: -10℃
℃℃
℃~60℃
℃℃
℃
Operating: 0℃
℃℃
℃~40℃
℃℃
℃
Storage: -10℃
℃℃
℃~60℃
℃℃
℃
Weight w/o stand 50.72lbs 50.72lbs
Weight w/ stand 52.9lbs 52.9lbs
Gross Weight 62.84lbs 62.84lbs
Dimensions (WxHxD) 36.73 inches x 29.33 inches x
10.24 inches
36.73 inches x 29.33 inches x
10.24 inches
Carton Dimensions
(WxHxD)
41.34 inches x 32 inches x 12
inches
41.34 inches x 32 inches x 12
inches
