TITLE
Service Manual
LCD TV For 237-T11
Doc No. SM_237-T11_19Nov07
Version 1.2
Page 29/72
Company Confidential-DRAFT
5-8 Keypad Board
6. Factory Menu
To show the Factory Menu with multiple pages.press these buttons at the same time:
Source,VOL↓, CHN↓.The FACTORY MENU appears on-screen.
1. Loosen and remove 7 screws and safely
remvoe connector indicated by a red circle.
2. Safely remove the Keypad board.
Screw T3*8 Black
MT3*6-PH-CROSS-Black
To Next Page
