690-NC2
0690S20051 10-2
FRONT PANEL PARTS LIST
ITEM NO PART DESCRIPTION PART NUMBER
341 STRIKE-LATCH 0690-0149
701 PANEL-FRONT CONTROL 0690-0034-2
702 BRACKET-PROX. SWITCH 0690-0042
703 SWITCH-2 POSITION MAINTAINED KNOB 5708-6522
704 BLOCK-CONTACT 1NC 5708-6808
705 BLOCK-CONTACT 1NO 5708-6809
706 PUSHBUTTON-GREEN 5708-7806
707 PUSHBUTTON-RED 5708-7805
708 LIGHT-PILOT 1/2” SNAP-IN RED 5709-0009
709 LIGHT-PILOT 1/2” SNAP-IN GREEN 5709-0011
710 CONTROL-TEMPERATURE 5712-0015
711 COMPUTER-16 KEY 5712-3267
712 KNOB 5736-4005
713 BREAKER-CIRCUIT 2.5A MAGNETIC 5757-4125
714 SWITCH-MAGNETIC PROXIMITY DOOR 5757-8819
717 PUSHBUTTON-”STEAM” 5708-7801
718 BUZZER 5700-6051
719 STRIP-INSULATOR 0690-0155
NOTE
THE REMAINING PANELS AND COVERS ARE SHOWN ON THE LIST BELOW
BUT ARE NOT SHOWN ON ANY OF THE DRAWINGS IN THIS MANUAL.
ITEM NO PART DESCRIPTION PART NUMBER
050 PANEL-REAR FAN (375/460V) 0690-0038-101
PANEL-REAR FAN (208/240V) 0690-0038-102
101 COVER-TOP 0690-0001-002
102 COVER-HINGE SIDE 0690-0002
105 COVER-ASS’Y-RECESS POCKET 0690-0074K
108 COVER-ELECTRICAL SIDE REAR 0690-0003-201
109 PANEL-REAR RIGHT 0690-0018-2
110 PANEL-REAR CENTER 0690-0018-3
111 COVER-ELECTRICAL SIDE FRONT 0690-0003-202
112 DOOR-FUSE 0690-0141
FOR SERVICE PARTS CALL OLIVER PRODUCTS @ 800-253-3893
Revised 12/10/2012
