Troubleshooting
10-14 OPERATION GUIDE
Inside the Machine
1 Pull the paper cassette all the way out of the
machine. Remove any partially fed paper.
2 Open the front cover, and lift the developer unit
together with the toner container out of the
machine.
3 Remove the drum unit from the machine by holding
the green levers with both hands.
CAUTION: The fuser unit inside the machine is hot. Do
not touch it, as it may result in burn injury.
NOTE: The drum is sensitive to light. Never expose
the drum unit to light for more than five minutes.
To Next Page
