SYSTEM DIAGRAM
}This instruction manual gives description the modules which are connected in thick and broken lines in the following
diagram. For other modules, please refer to their instruction manuals.
* Reflected Light Lamp Housing
Halogen bulb:
U-LH100-3
(Power Supply TH4)
Mercury burner:
U-LH100HG
U-LH100HGAPO
Xenon burner:
U-LH75XEAPO
** For the modules without the model names, consult your dealer or the latest catalogues.
Eyepiece**
Module support
pillar or module
mounting block
Reflected
Light Lamp
Housing*
Reflected Light
Illuminator
BX-URA2
BX-RLA2
Revolving
Nosepiece**
Objective**
Illuminator
Mounting Holder
BXFM-ILH
Revolving
Nosepiece**
Objective**
Illuminator
Mounting
Holder S
BXFM-ILHS
Large Stand
SZ-STL
Observation Tube**
Intermediate tube**
Compact Reflected
Light Brightfield Illuminator
U-KMAS
Reflected Light
Lamp Housing*
Focusing Unit
BXFM-F
Counter Spring
BXFM-ILHSPU
Stand
U-ST
