Olympus BXFM Series - USING THE CONTROLS; Base and Power Supply Operations

6
BXFM
Illuminator Holder BXFM-ILH, Counter Spring BXFM-ILHSPU
}The BX-URA2 or BX-RLA2 reflected light illuminator can be installed. The BXFM-ILHSPU is used to reduce the load on
focusing due to the weight of the reflected light illuminator and its accessories.
Illuminator mount screw holes
Stand U-ST
Pillar
Power Supply TH4
POWER LED
Hand Switch TH4-HS
Brightness control knob
Mounting holes x 4
Specimen holder
Stage plate
REMOTE LED
Main switch
Brightness control knob
Lamp ON-OFF switch
“ I ”: ON, “ ”: OFF
