CH10/CH20 C. DISASSEMBLY AND ASSEMBLY PROCEDURES
C-3
±
10
GEAR ASS’Y Insert the gear ass’y Š into the groove of
coarse adj.shaft
±
11
and engage the big gear
A at the right side with the gear inside of
the cam
±
12
.
±
13
COARSE ADJ.
KNOB-L
±
14
FINE ADJ.
KNOB
OT1028 Apply adhesive on the screw thread of fine
adj. shaft
±
15
.
±
15
FINE ADJ.
SHAFT
OT2008 Apply grease on the sliding surface.
±
16
RING
±
17
FINE ADJ.
GEAR
Press in to 101 mm from the end of the
fine adj. shaft
±
15
. See Figure-A on previous
page.
±
18
RING
To Next Page
