11
DP12
Fig. 5
Fig. 6
4 Inserting (Removing) the SmartMedia
(Fig. 5)
#Make sure the main switch is set to “ " (OFF) before insertion.
#A 3.3 V SmartMedia card manufactured by Olympus or marketed in
stores can be used.
However, when using a non-Olympus 3.3 V SmartMedia, it may be
necessary to format it (see page 29).
#A 5 V SmartMedia marketed in stores cannot be used with this cam-
era system.
1. Open the card cover 1.
2. Hold the SmartMedia 2 so that the contact area faces downward, and
insert it all the way into the slot on the camera unit.
3. Close the card cover.
Removal
Push the inserted SmartMedia further into deep. This causes the
SmartMedia pop out so that you can remove it with your hand.
#Do not use other method than the above to remove the SmartMedia
or attempt simply pull it out of the slot.
Card Access Indicator LED (Fig. 6)
The CARD access indicator 1 blinks when an access is made to the
SmartMedia. Do not open the card cover or unplug the power cord while
the indicator is blinking.
#Otherwise, the picture data recorded in the SmartMedia may be
destroyed.
1
2
1
To Next Page
