8
2. When two or more intermediate tubes are used in a stack, the periphery of the field of view may be obscured
depending on the observation tube and objective used together.
* Example of using two or more intermediate tubes:
With BX53 : Reflected light illuminator + Intermediate magnification changer
With IX series : IX73P2F, IX83P2ZF
3.
If the illumination used with the micr
oscope is the fluorescent light ring illumination or the illumination drived by the
alternate current such as the phase control light intensity control method, etc. and also if the light intensity voltage
becomes higher and the exposure time becomes shorter when combining the microscope and this camera, the
following phenomena occur due to the flickering of the illumination light.
· Flick
ering in the image displayed
· Variation of exposure
However, if the brightness can be adjusted by adjusting the illumination light level or by attaching/detaching the
attenuation filter, these phenomena can be avoided by adjusting the exposure time to 1/50 sec or longer. For
details such as the microscope model name which drives the illumination by the alternate current, etc., contact
Olympus distributor.
4.
P
erformance in combination use of this product and non-Olympus microscope has not been evaluated.
5.
When observing a lo
w contrast specimen or high reflectance specimen, the spot flare may be noticeable if the
aperture iris diaphragm is narrowed down close to the smallest diameter.
