169
EN
SAFETY PRECAUTIONS
11
LIMITATION, DIRECT, INDIRECT, INCIDENTAL,
CONSEQUENTIAL OR SPECIAL DAMAGES,
LOSS OF PROFITS OR LOSS OF USE),
WHETHER OR NOT OLYMPUS SHALL BE OR
SHOULD BE AWARE OF THE POSSIBILITY OF
SUCH POTENTIAL LOSS OR IMPAIRMENT.
The customer should package the Product
carefully using ample padding material to prevent
damage in transit. Once the Product is properly
packaged, ship the package to Olympus or the
Olympus Authorized Repair Service Center
location as instructed by the respective Olympus
Consumer Support Team.
When sending Products for repair service, your
package should include the following:
1) Sales receipt showing date and place of
purchase. Handwritten receipts will not be
accepted;
2) Copy of this limited warranty bearing the
Product serial number corresponding to
the serial number on the Product (unless it
is a model on which Olympus does not place
and record serial numbers);
3) A detailed description of the problem; and
4) Sample prints, negatives, digital prints (or
les on disk) if available and related to the
problem.
KEEP COPIES OF ALL DOCUMENTS. Neither
Olympus nor an Olympus Authorized Repair
Service Center will be responsible for documents
that are lost or destroyed in transit.
When service is completed, the Product will be
returned to you postage prepaid.
PRIVACY
Any information provided by you to process your
warranty claim shall be kept con dential and
will only be used and disclosed for the purposes
of processing and performing warranty repair
services.
For customers in Europe
“CE” mark indicates that this
product complies with the
European requirements for safety,
health, environment and customer
protection. “CE” mark cameras
are intended for sales in Europe.
Hereby, Olympus Imaging Corp.
and Olympus Europa SE & Co.
KG declare that this E-M5II is in
compliance with the essential
requirements and other relevant
provisions of Directive 1999/5/EC.
For details visit: http://www.
olympus-europa.com/
This symbol [crossed-out
wheeled bin WEEE Annex IV]
indicates separate collection of
waste electrical and electronic
equipment in the EU countries.
Please do not throw the
equipment into the domestic
refuse.
Please use the return and
collection systems available in
your country for the disposal of
this product.
This symbol [crossed-out wheeled
bin Directive 2006/66/EC Annex
II] indicates separate collection
of waste batteries in the EU
countries.
Please do not throw the batteries
into the domestic refuse.
Please use the return and
collection systems available in
your country for the disposal of
the waste batteries.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Olympus E-M5 Mark II and is the answer not in the manual?

Olympus E-M5 Mark II Specifications

General IconGeneral
Megapixel16.1 MP
Camera typeMILC
Sensor typeLive MOS
Image stabilizerYes
Total megapixels17.2 MP
Image sensor size4/3 \
Image formats supportedJPG, MPO, RAW
Supported aspect ratios1:1, 3:2, 3:4, 4:3, 16:9
Maximum image resolution4608 x 3456 pixels
Image stabilizer locationBody
Still image resolution(s)4608x3456, 3200x2400, 1280x960
Lens typeStandard
Filter size62 mm
Optical zoom- x
Focal length range12 - 40 mm
Lens mount interfaceMicro Four Thirds (MFT)
Minimum aperture number-
Number of diaphragm blades7
Lens structure (elements/groups)14/9
Maximum focal length (35mm film equiv)80 mm
Minimum focal length (35mm film equiv)24 mm
FocusTTL
Focus adjustmentAuto/Manual
Auto Focus (AF) points800
Auto focusing (AF) modesContinuous Auto Focus, Tracking Auto Focus
Closest focusing distance0.2 m
Light meteringCentre-weighted, Spot
ISO sensitivity100, 200, 1600, 25600
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)25600
ISO sensitivity (min)200
Light exposure controlProgram AE
Light exposure correction±5EV (1/2; 1/3 EV step)
Fastest camera shutter speed1/8000 s
Slowest camera shutter speed60 s
Flash modesAuto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed0.000125 s
Shoe mounting point typeHot shoe
Flash exposure correction±3EV (1/2, 1/3, 1 EV step)
Built-in flashNo
Power source typeBattery
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate60 fps
Video formats supportedAVI, MOV
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Resolution at capture speed1280x720@25fps, 1280x720@50fps, 1280x960@30fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps, 640x480@30fps
Memory slots1
Internal memory- MB
Compatible memory cardsSDHC, SDXC
Display diagonal3 \
Display aspect ratio3:2
Display resolution (numeric)1037000 pixels
Magnification2 x
Viewfinder typeElectronic
USB version2.0
USB connectorMicro-USB B
HDMI connector typeMicro
Scene modesBeach, Candlelight, Children, Documents, Fireworks, Night, Night portrait, Panorama, Portrait, Snow, Sports, Sunset, Landscape (scenery)
Image editingResizing, Rotating, Trimming
Photo effectsBlack&White, Muted, Sepia, Vivid
White balanceAuto, Custom modes
Shooting modesAperture priority, Auto, Lens priority, Manual, Movie, Program, Scene, Shutter priority
Camera playbackHighlights, Movie, Single image, Slide show
Self-timer delay2, 3, 5, 10, 12, 20, 30 s
Camera file systemDCF, DPOF, Exif, PRINT Image Matching III, RAW
Compatible productsFL-50R, FL-36R, FL-20, FL-14, FL-300R, FL-600R
Image quality adjustmentSaturation
On Screen Display (OSD) languagesBUL, CHI (SIMPL), CHI (TR), CRO, CZE, DEU, ENG, ESP, EST, FIN, FRE, GRE, HUN, IND, ITA, JPN, KOR, LAV, LIT, NOR, RUM, RUS, SER, SLK, SLV, THA, TUR, UKR
Battery typeBLN-1
Product colorSilver
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)-10 - 40 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)30 - 90 %
Cables includedAV, USB
F-number (relative aperture)2.8
Weight and Dimensions IconWeight and Dimensions
Depth44.5 mm
Width123.7 mm
Height85 mm
Weight417 g
Lens length84 mm
Lens weight382 g
Lens diameter69.9 mm
Weight (including battery)469 g
