Olympus FL-600R - Getting Started; Loading Batteries; Attaching to the Camera

8 EN
Loading Batteries
Loading Batteries
1
Open the battery compartment cover.
2
Insert the batteries with correct +/– polarity.
3
Close the battery compartment cover.
Attaching to the Camera
Attaching to the Camera
Confi rm that both the camera and electronic fl ash are off. Attaching or removing the electronic
fl ash while either the fl ash or the camera is on may result in malfunction.
3
2
1
1
Slide the latch in the direction opposite to that
indicated by the [LOCKX] icon (
1
).
2
Slide the fl ash into the hot shoe until it clicks securely
into place (
2
).
3
Slide the latch to the [LOCKX] position (
3
).
• To remove the fl ash, slide the latch in the direction
opposite to the [
LOCKX] arrow and slide it from the shoe.
