Chapter 2 Instrument nomenclature and functions
 For 6.2-mm type (IV8635X1)
Stereo optical adapter
Objective lens
Illumination
Nut
Illumination
Objective lens
Product abbreviation
See “Optical adapter specifications” (page 195)
Nut
Objective lens
O-ring
Connecting screw
Optical adapter
positioning groove
Product abbreviation
See “Optical adapter specifications” (page 195)
Electrode
Electrode
Positioning pin
(Optical adapter internal view)
Channel
Product abbreviation and set numberProduct abbreviation and set number
