Chapter 2 Instrument Nomenclature and Specifications
LF-TP/DP/GP OPERATION MANUAL
2.2 Endoscope Functions
1. Bending Section
Moves the Distal End of the endoscope when the UP/DOWN Angulation
Control Lever is operated.
2. UP/DOWN Angulation Control Lever
When turned in the “U” direction, the Bending Section moves UP; when
turned in the “D” direction, the Bending Section moves DOWN.
3. Suction Valve (MD-493)
Depresses the Suction Lever to activate suction. Note that the Biopsy Valve
must be attached.
4. Single-use Biopsy Valve (MAJ-210) or Biopsy Valve (MD-495)
A syringe may be inserted into the valve for feeding and aspirating fluids.
5. Suction Channel
Functions as: Suction Channel; fluid feed channel (from a syringe
connected to the Biopsy Valve).
6. Eyepiece Frame (Viewfinder)
The Viewfinder contains an index mark indicating the UP direction of the
Bending Section.
7. Diopter Adjustment Ring
Adjusts the operator’s focus. This does not affect focusing for photography.
8. Miniature Light Source (MAJ-524, Optional)
Includes the lamp and a Lithium Battery. Transmits light to the endoscope.
2.3 Specifications
Environment
Operating
environment
Ambient temperature 10 – 40C (50 – 104F)
Relative humidity 30 – 85%
Atmospheric pressure 700 – 1060 hPa
(0.7 – 1.1 kgf/cm
2
)
(10.2 – 15.4 psia)
Transportation and
storage
environment
Ambient temperature –47 to 70C (–52.6 to 158F)
Relative humidity 10 – 95%
Atmospheric pressure 700 – 1060 hPa
(0.7 – 1.1 kgf/cm
2
)
(10.2 – 15.4 psia)
