3-5
OEP-3 V1 (UC)
1. INT 4Fsc adjustment (NTSC)
Conditions for adjustment
1. SOURCE/MEMORY: MEMORY
2. NTSC/PAL: NTSC
Spec.
TP405 (B-6): 14 M
1,431,818 ±80 Hz
Adjustment
1CT401(B-6): 14.3
2. INT 4Fsc adjustment (PAL)
Conditions for adjustment
1. SOURCE/MEMORY: MEMORY
2. NTCS/PAL: PAL
Spec.
TP404(A-6): 17M
1,773,447.5 ±80.0 Hz
Adjustment
1CT403 (A-5): 17.7
3. INT 4Fsc adjustment (PAL)
Conditions for adjustment
1. SOURCE/MEMORY: MEMORY
2. NTCS/PAL: PAL
Spec.
TP406 (B-5): VCO DC
2.0 ±0.2 Vdc
Adjustment
1CT402 (B-5): 14.1
4. Picture adjustment
Conditions for adjustment
1. VA ADJUST MODE
2. INPUT SELECT: RGB
3. AGC: OFF
4. NTSC/PAL: NTSC
Spec.
Monitor
Adjust so that the red (or yellow, magenta, or
white) in the diagonally striped portion is the
maximum.
Adjustment
[SERVICE MENU3]
[PICTURE:]
