3-6
OEP-3 V1 (UC)
6. B-drive adjustment
Conditions for adjustment
1. VA ADJUST MODE
2. INPUT SELECT: RGB
3. AGC: OFF
4. NTSC/PAL: NTSC
Spec.
Monitor
Adjust so that the white in the diagonally
striped portion is the maximum.
Adjustment
[SERVICE MENU3]
[B-DRIVE:]
7. AGC REF adjustment
Conditions for adjustment
1. VA ADJUST MODE
2. INPUT SELECT: RGB
3. AGC: ON
4. NTSC/PAL: NTSC
Spec.
Monitor
Adjust so that the white in the diagonally
striped portion is the maximum.
Adjustment
[SERVICE MENU3]
[SUB-BRIGHT:]
5. G-drive adjustment
Conditions for adjustment
1. VA ADJUST MODE
2. INPUT SELECT: RGB
3. AGC: OFF
4. NTSC/PAL: NTSC
Spec.
Monitor
Adjust so that the yellow (or white) in the
diagonally striped portion is the maximum.
Adjustment
[SERVICE MENU3]
[G-DRIVE:]
