Chapter 3 Installation and Connection
27
VIDEO SYSTEM OTV-SI
Installation on the compact trolley (TC-C2)
1.
Refer to the instruction manual of the compact trolley (TC-C2), and set up
the compact trolley as instructed.
2. Place the compact trolley on a level surface. Lock the caster brakes (see
Figure 3.1).
Figure 3.1
3. Install the shelf of the compact trolley as described in the compact trolley’s
instruction manual.
4. Place the instrument on the trolley’s shelf, making sure that it is level.
Installation in another location
Place the instrument on a stable, level surface. Do not obstruct the ventilation
grilles with ancillary equipment, etc.
Caster
Brake caster Brake release
