OMA 528C - Page 27

MONTAGGIO
I
ATTENZIONE
DURANTEILMONTAGGIONONE’AMMESSO
NESSUNESTRANEOAILAVORI.
MONTAGGIOSTRUTTURAMOBILE(PIATTAFORMA)
1-Nell’areapredestinataall’installazionedelpontepredisporre4
cavallettidisostegnoaventilamedesimaaltezza,adeguatialpeso
dasostenere(250kg.cadauno)edisporlicomeinfigura(A-B-CD).
Fig.39
2-Toglieredall’imballolecolonne(1-2-3-4),lepedane(7-8),la
centralinaidraulica(10)egliaccessori.
3-Predisporresui2cavalletti(A-D)lapedana(7)conleduetra
-
verse(5-6)
4-Posizionarelatraversa(5)sulcavalletto(B)edavvitarlasulla
pedana(7)medianteleviti(15)M12x25elerosettedentate(16)
Ø12x20.
Durantequestafaseéimportanteverificarechelefunisianoinpo
-
sizionecorretta(vedipart.“C”inFig.40).
5-Posizionaresulletraverse(pos.5-6,Fig.39)lapedana(8).
6-Verificarelasquadraturaelediagonalidell’assiemetraver
-
se-pedane;quindiserrareafondoleviti(15)difissaggiodellepe
-
dane(7-8).
ASSEMBLY
I
WARNING
UNAUTHORISEDPERSONSMUSTNOTBEAD
-
MITTEDDURINGASSEMBLYOPERATIONS.
ASSEMBLYOFMOVABLESTRUCTURE(PLATFORM)
1-Place4trestlesofthesameheightandsuitablysturdytohold
250kgeach,intheareawhereyouintendtoinstallthelift.Position
thetrestlesasshowninthefigure(A-B-C-D).
Fig.39
2-Removethepostsfromthepacking(1-2-3-4),togetherwiththe
platforms(7-8),thehydraulicpowerunit(10)andaccessories.
3-Placetheplatform(7)ontwotrestles(A-D)togetherwiththe
twocross-pieces(5-6)
4-Placethecross-piece(5)ontrestle(B)andsecureittotheplat
-
form(7)usingM12x25screws(15)and12x20toothedwashers
(16).
Duringtheseoperationscheckthatthesteelcablesarecorrectly
positioned(seeview“C”infig.40).
5-Placetheplatform(8)onthecross-pieces(pos.5-6,fig.39).
6-Checksquaringandthediagonalsofthecross-piece-platform
assembly;then,fullytightenthescrews(15)securingtheplatforms
(7-8).
25
15
16
10
9
A
C
B
D
8
7
6
5
3
4
1
2
15
16
NO!
