To set automatic power reduction:
1) Ensure that the EDIT option is selected; otherwise, turn the knob to select it, then press to
confirm. A value will be displayed after OFF or ON.
2) Turn the knob to set OFF or ON according to your requirements, then press to confirm. A
value will be indicated after reduce.
3) Turn the knob to change the power reduction percentage, then press to confirm. The first
number (hour) will be highlighted after from.
4) Turn the knob to change the hour in which the power reduction will start (24-hour clock),
then press to confirm. The second number (minutes) will be highlighted after from.
5) Turn the knob to change the minute in which the power reduction will start, then press to
confirm. The first number (hour) will be indicated after to.
6) Repeat steps 4 and 5 to set the time in which the transmitter will return to normal power.
7) Using the knob, select OK to save the settings, EDIT to make further changes, or ABORT to
exit without saving the new settings, then press to confirm.
- MODEM setting
If the transmitter is equipped with an optional modem, its parameters can be defined via this
screen. For further details, refer to the documentation provided with this option.
If a modem has not been installed, the screen will indicate Modem not present.
- Hidden menus (under level 3 password)
Beside the two level 1 and level 2 passwords, a third password, called “level 3 password” is
available. It’s preset during the production, it’s always active and allows to access the SETUP
sub menu and the one which allows the activation/change of the level 1 and level 2
passwords even when the user has activated and forgotten them.
There are two hidden menus which can be accessed only by entering the level 3 password.
Briefly, accessing the SETUP menu by means of the level 3 password allows to:
• Access the SETUP sub menu and the one which allows the activation/change of the level 1
and level 2 passwords even when the user has activated and forgotten them.
• Change the level 3 password in order to change the one preset during the production of the
equipment.
- Accessing the level 3 password
To access the SETUP submenu when you have forgotten the level 1 or level 2 password
currently active:
1) Use the knob to select the SETUP menu and press it to confirm.
2) When the password is prompted, enter the level 3 password which was set during the
production to A B C D.
